DESCRIPTION
The bi-wire variation of our Hyper cable family. Bi-wire cables can offer performance benefits when the two halves of the loudspeaker's crossover are electrically ‘separated’ to allow bi-wiring) (and bi-amping, if so desired).
A sophisticated bi-wire cable engineered to offer a high level of transparency and wide dynamic range.
The cable employs conductors comprising 72 0.25mm² high-purity OFC (Oxygen Free Copper) strands encapsulated within a carefully selected high-efficiency PTFE (Teflon™) dielectric coating. The resultant conductor is embedded within an anti-vibration filler and finished in the Hyper gloss black sleeve.
Our latest-generation Achromatic Z-plug is a proprietary low-mass, self-cleaning, precision-crimped (cold-weld) speaker connector fitted as standard
FEATURES
- Achromatic Z plug or Spade connector
- OFC Conductors
- PEF
- Twin-core round
SPECIFICATIONS
-
CONSTRUCTION Concentric multicore LF/MF, Solid core HF (1.2mm)
-
MATERIAL 6n OFC
-
DIELECTRIC PTFE (Teflon™)
-
SCREEN none
-
CAPACITANCE 163.98 pF/m
-
INDUCTANCE 0.2303 µH/m
-
RESISTANCE 0.0060 Ohms/m
-
VOP 0.69
-
OUTSIDE DIAMETER 8.5mm
