AV Gear AVG-DMM1616

  • Modular Matrix switch Video Processor and Scaler cage 16×16

The DMM1616 is a 4K supported, seamless switching, high−performance modular matrix switcher chassis for various digital and analog signals. The modular design is popular with 4 input slots & 4 output slots, supporting a maximum of 16 inputs and 16 outputs. The AVG-DMM1616 is a Modular Matrix Video Switcher and Scaler Cage supports 5 Video formats across the various I/O cards.

Features

  • Supports 4Kx2K & 1080p 3D
  • Seamless switching.
  • Configurable and flexible I/O with audio up to 64 x 64..
  • Available with a choice of I/O cards, HDBaseT, HDMI, optical, SDI and VGA/audio cards.
  • True cross-point switching, any input to any output.
  • Ultra-switching for instantaneous display.
  • Smart EDID management.
  • HDCP compatible.
  • Controllable via front panel, IR, RS232 and optional TCP/IP 2 way driver.

Specifications

Control
Serial control port RS-232, 9- female D connector Configurations 2 = TX, 3 = RX, 5 = GND
TCP/IP control RJ45 Port
Front Panel Push Button control
General
Power Supply 100VAC ~ 240VAC, Power 84W (Max)
50/60Hz Consumption
Temperature -10 ~ +40℃ Humidity 10% ~ 90%
Dimension W (*H*D) 483 x 133x 320mm (3U high) Weight 3.5Kg
