Enjoy incredible 8K video and 3D audio from the AVR-X1800H. It easily fills small to medium-size rooms with brilliant audio from a 7.2 or 5.2.2 set up with Dolby Atmos and DTS:X. And with HEOS® Built-in, you can wirelessly stream music and share with every HEOS-enabled speaker around your home.
Multichannel Surround
DTS HD Master / DTS:X / DTS:X Pro
Yes / Yes / No
DTS Neo:6 / DTS Neural:X
No / Yes
DTS Virtual:X
Yes
Dolby TrueHD / Dolby Atmos / Dolby Atmos Height Virtualization / Dolby Atmos Music
Yes / Yes / Yes / Yes
Dolby ProLogic Il / Dolby Surround
No / Yes
Multichannel Stereo
Yes
Max. number of processing (preamp) channels
5.1
Sound Enhancements
Discrete Power Amplifier
Yes
Audyssey
MultEQ
Audyssey Dynamic EQ / Dynamic Volume
Yes / Yes
Compressed Audio Restorer
Yes
Network
Media Server
Yes
HEOS Wireless Multi-Room Technology
Yes
Bluetooth Re-Transmit for Bluetooth Headphones
Yes (with volume control)
Alexa / Google Voice Assistant / Apple HomePod
Yes / Yes / Yes
Lossy Formats: MP3 / WMA / AAC
Yes / Yes / Yes
Lossless Formats: FLAC / ALAC / WAV
Yes / Yes / Yes
Lossless Formats: FLAC HD 192/24 / WAV 192/24 / ALAC 192/24
Yes / Yes / Yes
DSD Audio Streaming
Yes (2.8/5.6MHz)
FLAC HD 192/24
Yes
WAV 192/24
Yes
ALAC 192/24
Yes
Gapless playback
Yes (FLAC, WAV, ALAC ,DSD)
AirPlay Audio Streaming
Yes (AirPlay2)
Internet Radio
Yes (TuneIn)
Spotify
Yes (connect)
Pandora
Yes
SiriusXM
Yes
Other Streaming Services
Amazon Music HD / Amazon Music / TIDAL / Deezer / iHeart Radio / Napster / Soundcloud / Mood Mix
Roon Tested
Yes
HEOS App Control
Yes
Compatible with Remote APP for Smart Phones
Denon AVR Remote
Compatible with Remote APP for Tablets
Android / iOS / Amazon Kindle
Ethernet Ports
Yes
Wi-Fi
Yes
Bluetooth
Yes
HDMI
HDMI Inputs: Back/Front
6 (3x 8K) / No
HDMI Outputs: Main/Zone
1 / No
HDMI max Resolution (8k / 4k)
8k/60 - 4k/120
HDMI to HDMI Scaling
up to 8K 60/50
HDMI: 8K / 4K / CEC / eARC
Yes / Yes / Yes / Yes
HDMI: Dolby Vision / HDR 10+ / Dynamic HDR /HLG
Yes / Yes / Yes / Yes
HDMI: ALLM / QMS / QFT / VRR
Yes / No / Yes / Yes
HDMI Pass-Though in Standby Mode
Yes
Multiroom / CI
HEOS Multiroom integrated
Yes
TV Sound grouping
Yes
Multiroom zones
2
Main room multichannel audio - Zone stereo downmix
Yes
Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog
Yes (2ch) / Yes (2ch) / Yes / Yes
Zone Audio Output: Speaker / Pre-Out
Yes / No
Webbrowser Setup
Yes
IP Control / RS232 Control / Web Control / App Control
Yes / No / Yes / Yes
Specifications
Number of Power Amps
7
Power Output (8 ohm, 20 Hz–20 Khz, 0.08% 2ch drive)
80 watts per channel
Power Output (6 ohm, 1 kHz, 0.7% 2ch drive)
120 watts per channel
Power Output (6 ohm, 1 kHz, 10%->1% 1ch drive)
145 watts per channel
Others
Compatible with Remote App for smart phones
Denon AVR Remote
Auto Speaker Setup by Microphone
Audyssey MultEQ XT
Front Display
1-Line FLD
GUI Languages
9
Voice Control - Works with Amazon Alexa
Yes
Voice Control - Google Assistant / Apple Siri
Yes
Graphic User Interface - GUI
High Definition 1080p
Setup Assistant
Yes
Quick Select Plus / Quick Select
Yes / No
Firmware Update by Network / USB
Yes / Yes
Variable Crossover
Yes
Optimized Bass Redirection
Yes
HDMI Diagnostic Mode
Yes
ECO Mode
Yes
Auto Power off
Yes
Sleep Timer
Yes
General
System Remote Control
RC-1257
Power Consumption
430W -> 440W
Power Consumption (No Sound, ECO on/off)
29W/39W
Standby Consumption in W
0.1
CEC Standby Consumption in W
0.5
Maximum Dimensions (W×D×H)
Antenna: Horizontal(mm)
Antenna: Vertical(mm)
434 x 151 x 339
434 x 215 x 339
Carton Dimensions (Packaging) (WxDxH)
523 x 435 x 232mm
Weight in kg
8.6 kg
Inputs/Outputs
HDMI In/Out
6 / 1
Analog In/Out
2 / No
Phono (MM) In
Yes
Digital in: Optical/Coaxial
2 / No
Multi-Room Out: Analog/Digital
1 / No
Subwoofer Out
2
Speaker Terminal: Gold-Plated Screw / Regular Screw
No / Yes
Number of Speaker Terminals
7
Multi-Room Speaker Terminal
assignable
USB Audio Input Front
Yes
USB Power 5V/1.5A Rear
Yes
FM Tuner with RDS
Yes
