With bold cabinet dimensions that hark back to some of the 1970s most ambitious home loudspeakers, the Vintage Classic XII is a masterpiece of retro design meeting cutting-edge modern performance. From the outside, the large rectangular cabinet, walnut veneer and imposing black baffle truly embody those classic designs while delivering audio power handling and musical accuracy, dynamics and imaging of the best speakers of the 2020s. Built around a potent 300mm (12”) Iso Flare Driver with Fyne Flute roll surround, the Vintage Classic XII serves the most engaging musical performance in the largest of rooms. The Classic XII is equally at home in minimalist surrounds or the great hall of a country manor.
| System Type | 2 way, downwards firing port, with Bass Trax Tractrix diffuser |
| Recommended amplifier power (Watt RMS) | 20 - 350 |
| Peak power handling (Watt) | 700 |
| Continuous power handling (Watt RMS) | 175 |
| Sensitivity (2.83 Volt @ 1m) | 96dB |
| Nominal impedance | 8 Ohm |
| Frequency response (-6dB typical in room) | 25Hz- 26kHz |
| Drive unit complement | 1 x 300mm Iso Flare point source driver, multi-fibre bass / midrange cone, with 75mm titanium alloy dome compression tweeter, ferrite magnet system |
| Crossover frequency | 750Hz |
| Crossover type | Bi-wired passive low loss, 2nd order low pass, 2nd order high pass |
| System adjustments | High frequency energy (750Hz - 26kHz) +/- 3dB Presence (2.5kHz - 5.0kHz) +/- 3dB |
| Dimensions - H x W x D | 1102 x 572 x 591mm (43.4 x 22.5 x 23.3") |
| Weight - Each | 54.5kg |
| Finishes | Walnut |
| Cabinet Construction | High density fibreboard, walnut veneered with extensive internal bracing |
| *All dimensions are approximate |
