The Vertere Imperium Precision Motor Drive is a high-quality motor drive that enhances the musical performance of vinyl records and pays exceptional attention to detail in its design. It features a programmable microprocessor, fully regulated voltage rails, and a bi-phase bridged amplifier for precision sine and cosine waves.
Vertere Imperium Precision Motor Drive
Imperium Precision Motor Drive is based on our Reference Motor Drive and utilises some of its most advanced control circuit design, including a simplified power supply and control functions. The Imperium enhances the musical performance and makes the experience of listening to vinyl on the RG-1 or the SG-1 closer to the original master.
Exceptional attention to detail has been given to the whole design, including a gold-plated two-layer PCB utilising extensive ground planes, fully regulated voltage rails powering different circuit sections, and carefully selected components, ensure in-control and 'clean' final delivery of power to the motor.
The PCB mixes SMD and thru-hole components using the best of both technologies. Copper foil shields the entire digital, microprocessor and DAC circuitry is first, and then the whole PCB is secondarily shielded using a stainless-steel shield plate.
The double screened programmable and updateable microprocessor digitally generates the sine and cosine waves (which are switchable to be ± 0, 0.25%, 0.5%) to the equally double screened DAC. The output of the DAC feeds two 'power amps' provided by an extremely clean supply to drive the approximately 17V the motor requires.
Technical Specifications
Input Power: 100-120V or 220-240 Vac (50/60 Hz)
Internal Power Supply: Linear, Int. Switchable
Fully Regulated Main Power Rail
Plus two further Regulated Supplies
Output Drive: Bi-phase Bridged Amplifier
Output: Precision Sine & Cosine Waves
Speed Selection: Speed Selection
Speed Adjustment: 0.25%, -0.75%, 0.0, +0.25%, +0.75%
Output Voltage: 17.5 Vac rms (Two Phases)
LED Illumination Output: 12Vdc (Fixed)
