The SDA-4600 is a versatile 4-channel Class D power amplifier designed to deliver maximum power while taking up minimal rack space. Each channel is rated to deliver 600W into 8 ohms and adjacent channel pairs can be bridged to deliver 1,200W into 8 ohms. This flexible channel configuration makes this an ideal amplifier to power larger LCRs and subwoofers in JBL Synthesis immersive audio systems. Powerful built-in DSP allows for custom loudspeaker tuning and full external control allows for complete and easy system integration.
SDA 4600 Specification
High-performance installation amplifier | |
---|---|
4 x 600 Watts (Bridgeable to 1200 Watts) | |
Frequency Response | ±0.25 dB |
BLU Link Signal-to-Noise Ratio | >108 dB |
Analog Input Signal to Noise Ratio | >104 dB |
Total Harmonic Distortion | 0.35% |
Voltage Gain (at Maximum Level Setting) | 34 dB |
Damping Factor | >1000 |
Input Impedance | 10 kOhms, 5 kOhms |
Maximum Input Level before Compression | +20dBu |
7-Volt Capable | |
Dimensions (H x W x D) | 3.5” x 19” x 14.25” (8.75 cm x 48.3 cm x 36 cm) |
Weight | 20.1 lbs (9.12 kg) |
Product Type:
Power Amplifiers
Amplifiers
