Mission ZX-C1 Centre Speaker
The ZX-C1 2-way Centre Speaker is the latest in a long line of distinguished and revered Mission loudspeakers and joins more recent Award-winning products. The ZX series represents the most technologically advanced loudspeakers in the Mission family, with a distinct ID that will complement the finest electronics and décor.
Mission ZX incorporates purpose-designed bass driver cones, precision-engineered motor systems, advanced treble units, and more. As ever with Mission products; ‘Music leads, Technology Follows’. No compromise.
Designed to stand out head and shoulders above the competition, the Mission ZX range oozes luxury in appealing gloss black and gloss white finishes. Carefully selected trims and driver materials do more than catch the eye and complement the technology at play. The Mission ZX series has an all-inclusive design that continues to tell the story of the music, not just deliver hi-fi sound.
Mission ZX-C1 Specifications
| General Description |
2-way centre speaker |
| Enclosure Type |
Bass reflex |
| Transducer Complement |
2-way |
| Bass Driver |
5.25" (130mm) aluminium cone x2 |
| Midrange Driver |
|
| Treble Driver |
1.5" (38mm) ring dome |
| AV Shield |
No |
| Sensitivity (2.0V @ 1m) |
89dB |
| Recommended Amplifier Power |
25-150W |
|
|
| Peak SPL |
109dB |
| Nominal Impedance |
8 Ohms compatible |
| Minimum Impedance |
4 Ohms |
| Frequency Response(+/-3dB) |
48Hz ~ 24kHz |
| Bass Extension(-6dB) |
45Hz |
| Crossover Frequency |
2.5kHz |
| Dimensions (HxWxD) |
180 x 600 x (300+12)mm |
| Net Weight |
31.2k12.6kg/pcsg/pcs |
