Orientation Vertical |
Depth 3.375" (8.57 cm)
|
Driver Complement(1) 6.5" (16.51 cm) d (Round) Composite Polymer Cone with Butyl Rubber Surround - Mid/Woofer (1) 1" (2.54 cm) d (Round) Swivel Mount, Silk Dome - Tweeter |
Grille Dimensions8.875" (22.54 cm) h x 14.375" (36.51 cm) w |
IN-WALL MOUNT
|
Available Orientations Vertical |
Shape Round |
Dimensions12.75" (32.39 cm) h x 7.25" (18.42 cm) w |
Flush Mounting Depth2.875" (7.3 cm) - |
AUDIO QUALITY
|
Total Frequency Response 32 Hz → 27 Hz |
Nominal Impedance 8 ohms |
Sensitivity (1 watt @ 1 metre)90 dB |
Lower and Upper -3dB Limits 50 Hz → 25 Hz |
EXTERNAL AMPLIFIER
|
Recommended Amplifier Power Per Channel 10 watts → 125 watts |
INPUTS
|
Audio Inputs
|
Speaker Inputs (1) Pair of Push Connectors - Gold Plated
|
|
In-Ceiling Speaker - V60
|
Depth3.75" (9.53 cm) |
Driver Complement(1) 6.5" (16.51 cm) d (Round) Composite Polymer Cone with Butyl Rubber Surround - Mid/Woofer (1) 0.75" (1.91 cm) d (Round) Swivel Mount, Silk Dome - Tweeter |
Grille Dimensions 9.625" (24.45 cm) diameter |
IN-CEILING MOUNT
|
Shape Round |
Dimensions8.188" (20.8 cm) diameter |
Flush Mounting Depth3.25" (8.26 cm) |
AUDIO QUALITY
|
Total Frequency Response 33 Hz → 27 Hz |
Nominal Impedance 8 ohms |
Sensitivity (1 watt @ 1 metre) 89 dB |
Lower and Upper -3dB Limits50 Hz → 25 Hz |
EXTERNAL AMPLIFIER
|
Recommended Amplifier Power Per Channel10 watts → 100 watts |
INPUTS
|
Audio Inputs
|
Speaker Inputs(1) Pair of Push Connectors - Gold Plated |
PSW111 - Powered Subwoofer
|
Orientation Vertical |
Height12.13" (30.81 cm) |
Width11" (27.94 cm) |
Depth13" (33.02 cm) |
Weight20.3 lbs (9.21 kg) |
Subwoofer Array Driver Enclosure Type Vented, Downward Firing Port |
Subwoofer Array Driver Complement• (1) 8" (20.32 cm) d (Round) Dynamic Balance polymer composite cone - Subwoofer |
AUDIO QUALITY
|
INPUTS
|
Audio Inputs"LFE (Unfiltered) Stereo Line Lavel - (2) RCA" |
Speaker Inputs• (2) Pair of spring Terminals - Gold-Plated |
INTERNAL AMPLIFIER
|
Power 300 |
