Shanling EA5 Streaming DAC All-In-One Music Player

Shanling EA5 All In One Music Centre

Designed as a multifunctional music centre for your desktop Hi-Fi system, working perfectly all alone or in combination with your other devices.

Heart of EA5 is its digital player system, giving you easy access to a range of streaming services or working with your music library. Just insert MicroSD card, attach hard drive or connect EA5 to your local Wi-Fi network and music will start. And all of that can be controlled remotely from an app on your phone.

Specifications

General

• Dimension: 238 x 188 x 55 mm

• Screen: 4.7 inch 720 x 1280 IPS touch screen

• Operating System: Closed Android, with deeply customised to prioritise highest quality audio playback

• Storage: up to 2TB Micro SD card (purchased separately)

Speaker Output Section

• Output Power: 2 x 50w @ 4 ohm / 2 x 32w @ 8 ohm

• Frequency Response: 20Hz - 20kHz (-0.5dB Standard Mode)

• THD+N: 0.003% (A-Weighted @ 0.5V)

• Signal to Noise Ratio: 107 dB @ 8 ohm (A-Weighting)

• Noise: 83dB @ 8ohm (A-Weighting)

• Channel Separation: 68 dB @ 8 ohm

Headphone Section

• Output: 570mW (single ended)

• Output impedance: 0.8 Ohm (single ended)

• Channel separation: 75 dB (single ended)

• Recommended headphone impedance: 8-300 ohms

• Distortion: 0.0024%

• Signal to Noise Ratio: 118 dB @ 32 ohm (A-weighting)

• Dynamic Range: > 112 dB @ 32 ohm (A-weighting)

• Output port: 6.3mm (single ended)

DAC Section

• DAC Model: AK4493EQ

• Sampling rate: up to 768kHz / 32 bit, Native DSD512 Software

• USB input: connect to use as sound device for external transport such as computer or tablet/phone

• USB Host port for external HDD connectivity

• Digital Coaxial and Optical inputs

Streaming Section

• DLNA/UPNP/Airplay network connectivity

• 2-way Bluetooth, stream from a source over bluetooth, or stream from EM5 to bluetooth headphones

• Bluetooth Codecs: LDAC, LHDC, SBC, aptX (trasmit); LDAC. SBC (receive)

• Spotify, Tidal, Qobuz, QQ music, Deezer, Amazon Music apps available

• MQA support 8x playback from stored files, streaming apps and USB input

• Ethernet port

• 2.5G / 5G Dual Band Wi-Fi

• OTA firmware updates

• Shanling Eddict Player app gives complete control on smartphones and tablets

Analogue Section

• Analogue RCA input

• Analogue RCA output
