| D/A Converter |
ESS Sabre32 Reference ES9018K2M |
| Input Sampling Rates |
Optical, Coaxial: 44.1kHz~192kHz; USB: 44.1kHz~384kHz (PCM)/DSD64, DSD128, DSD256 |
| Rated Output Power |
2 x 45W (8ohm)/2x65W (4ohm) |
| Total Harmonic Distortion |
< 0.005% (30W, 8ohm) |
| Frequency Response |
20Hz-20kHz (+/-0.5dB) |
| Input Sensitivity |
480mV (RCA AUX IN); 4.1mV (phono MM) |
| Input Impedance |
10Kohm (AUX) ; 47Kohm //100pF (phono MM) |
| Signal to Noise Ratio (S/N) |
≥108dB (A-weighted, ref.45W) |
| Pre Output Level |
4 |
| Pre Output Total Harmonic Distortion (THD) |
< 0.003% |
| Pre Output Signal to Noise (S/N) |
>110dB (A-weighted) |
| Bluetooth Profile |
A2DP |
| Bluetooth Codec |
aptX (priority), SBC |
| USB Input |
1 x USB (B-type) |
| Digital Audio Inputs |
2 x Optical TOSlink ,1 x RCA COAX |
| Digital Audio Outputs |
1 x Optical TOSlink ,1 x RCA COAX |
| Analog Inputs |
2 x RCA (AUX1, AUX2) ,1 x RCA (phono MM) |
| Analog Output |
1 x RCA (PRE OUT) |
| Power Requirement |
220-240V ~ 50/60Hz 100-120V ~ 50/60Hz |
| Dimensions W x H x D (mm) |
326 x 146 x 276 (Wood) |
| Carton Size W x H x D (mm) |
475 x 248 x 450 |
| Net Weight |
8.30kg (Walnut)
|
| Gross Weight |
10.60kg (Walnut)
|
| Finish |
Walnut |
