Van den Hul MC-ONE Special Moving Coil Cartridge


Regular price$3,175.00
/
10 interest free payments from $317.50 with


The MC-ONE Special is a high-quality, handbuilt moving coil cartridge with improved resolution capabilities and output voltage. It has a production time of about two weeks and comes with a range of specifications, including stylus shape, frequency range, tracking force, and recommended load impedance.



THE MC-ONE SPECIAL MC CARTRIDGE

DESCRIPTION

The MC-ONE Special from Van Den Hul is a custom handbuilt moving coil cartridge; Special selected version of the MC–10 Special with 0.65 mV/channel.

The designation “Special” in this cartridge’s name indicates important improvements over its previous version:

  • The cartridge is equipped with a thicker frontpole and an extra small magnet, both further enhancing its resolution capabilities and output voltage.

    Production time:
    The production time for a MC-ONE Special cartridge after ordering is about two weeks.



    SPECIFICATIONS

    Stylus Shape: VDH - I
    Stylus Radii: 3 x 85 Micron
    Frequency Range: 5 - 50.000 Hz
    Tracking Force: 13.5 - 15.0 mN
    Static Compliance: 28 Micron/mN
    Tracking Ability at 15mN at 315Hz: 70 - 80 Micron
    Output Voltage at 1 kHz at 5.7 cm/s eff.: 0.65 mV RMS
    Channel Unbalance: < 0.5 dB
    Channel Separation at 1kHz / 10kHz: > 35 / > 30 dB
    Equivalent Stylus Tip Mass: 0.35 Milligram
    System Weight: 8.2 Gram
    Vertical Tracking Angle : 22 Degrees
    Load Capacitance: non critical
    Recommended Load Impedance: 200 Ohm
    Recommended Eff Tone arm Mass: 8 - 12 Gram
    Moving Coil Resistance per channel: 9 Ohm +/- 10%
