Brand: Vertere

No reviews

Regular price$545.00
/
10 interest free payments from $54.50 with


The Vertere Magneto Dual Moving Magnet Phono Cartridge is a high-quality cartridge designed to provide exceptional sound quality with its dual magnet design and finely finished elliptical stylus. It also features replaceable stylus, integrated stylus guard, and easy alignment assist marking, making it a great choice for any starter record playing system.

Vertere Magneto Dual Moving Magnet Phono Cartridge

Vertere Magneto Dual Moving Magnet Phono Cartridge is designed and manufactured
to exacting standards to provide an unparalleled musical experience in its class.

The Dual Magnet design replicates the structure of the cutter head.

A ‘V’ form two magnet design mimics the Left & Right channel sides of the record groove. This feature, with the permalloy centre shield plate, provides a higher frequency response with electrical crosstalk typically better than 40dB.

The Magneto utilises a finely finished Elliptical stylus to ensure outstanding tracking ability and super quiet tracing of the record groove. Use of laminated Para-toroidal coils with ‘V’ geometry of the magnets also gives rise to higher efficiency in generating the output signal.

 The Magneto is an absolutely gem of a cartridge for any starter record playing system.

Features

  • Replaceable Stylus

  • Integrated Stylus Guard

  • Stainless Steel Fixing Bolts, Washer & Hex Thumb Nuts

  • Easy Alignment Assist Marking

Technical Specifications


Frequency Response
20 - 23,000Hz

Channel Separation
27dB (1kHz)

Output Channel Balance
1.5dB (1kHz)

Output Voltage
4.0mV (1kHz, 5cm/sec.)

Vertical Tracking Angle
23˚

Vertical Tracking Force Range
1.8 – 2.2g (2.0g standard)

Stylus Shape
Elliptical Bonded

Stylus Size
0.3 x 0.7 mil

Stylus Construction
Bonded Round Shank

Cantilever
Aluminium Tube

Coil Resistance
800Ω (DC)

Static Compliance
35 x 10⁶ cm/dyne

Dynamic Compliance
8 x 10⁶ cm/dyne (100Hz)

Recommended Load Impedance
47,000Ω

Recommended Load Capacitance
100 – 200pF

Weight
6.4g

Dimensions
17.3 (H) x 17.0 (W) x 28.2 (L) mm
